Stop tracing wires. Ask the AI.

Point MyPros+ at any wiring diagram. Ask where voltage comes from, which connector feeds what, or why a circuit is dead. Get the answer in seconds — with the page number.

MyPros+ AI reading and tracing circuits on an appliance wiring diagram
The old way
L1L2NGNDES 5XXP1 P2 P3 P4P5 P6 P7 P8P9 P10 P11 P12RELAY BDA1 A2 A3A4 A5 A6ELEMENTBA BKRBKWBLRY-7TEMP SNST1 T2 T3T4 T5DOOR SWD1 D2FAN MTRM1 M2 M3
45 minutes searching for one circuit path
M+The MyPros+ way
Where does bake element voltage come from on the FGES3065KFD?
1
Bake element voltage route
Bake element voltage routes from L2 through the Electronic Oven Control (ES 5XX) at connector P6, then outputs at terminal P9 (BA).
Wire colors: Y-7 to Y-3 from control board A5 to the element.
Service Manual — Wiring Diagram, p. 1-8

Trace any circuit

Ask where voltage comes from, which relay controls what, or what wire color goes where. The AI reads the diagram so you don't have to.

Every answer cites the page

No guessing. Every response tells you exactly which page of which document the answer came from.

Works with any brand

Frigidaire, Samsung, LG, GE, Whirlpool, Bosch — 78,000+ service documents across all major brands.

Read wiring diagrams dramatically faster.

See Plans →

7 days free · Credit card required
